Jekko 545

Maximum Lifting Capacity: 15,500 kg.

Maximum Working Height: 30 m (up to 32.5 m with certain configurations)

Maximum Radius: 28 m (30 m in specific setups)

Dimensions: 5.40 m (L) x 1.84 m (W) x 2.83 m (H)

Engine: Kubota V3307 diesel engine with 55.4 kW (74 HP) power

Travel Speed: Up to 2.5 km/h1

Gradeability: 20°

Counterweight: 3,500 kg

Features

Articulated Design:

·      Combines a truck-loader crane with a self-propelled tracked vehicle for enhanced mobility and operation in confined spaces.

Continuous Rotation:

·      Slew ring allows limitless 360° rotation for flexible positioning.

Stabilization System:

·      Adjustable outriggers with a stabilization area of up to 6,700 x 6,700 mm ensure safety on uneven surfaces.

Compact Design:

·      Compact dimensions allow easy transport and operation in tight spaces.

The Jekko JF545 is ideal for construction, industrial maintenance, glass installation, and other specialized tasks requiring precision and adaptability.

‍
